Cost-effective, time-consuming field termination, high-density fiber patching in data centers
| Item | Parameters | ||||
| Single mode | Multimode | ||||
| Insertion Loss(dB) | ≤0.7 | ≤0.7 | |||
| (≤0.35 low insertion loss is optional) | |||||
| Return Loss(dB) | UPC | ≥45 | ≥25 | ||
| APC | ≥55 | / | |||
| Durability(dB) 500 mating times | △IL ≤0.2, △RL≤5 | ||||
| Fiber Type | G652D (G657A and G657B fiber are optional) | OM3, OM4 | |||
| Cable | Type | Round cable (flat ribbon cable is optional) | |||
| Jacket Material | PVC (LSZH is optional) | ||||
| O. Diameter (mm) | 3.0 | ||||
| Temperature(°C) | Operating | -20~+75 | |||
| Storage | -20~+75 | ||||
| Item | Parameters | |||
| Single mode | Multimode | |||
| Insertion Loss(dB) | ≤0.5 | ≤0.5 | ||
| (≤0.35 low insertion loss is optional) | ||||
| Return Loss(dB) | ≥65 | ≥25 | ||
| Durability(dB) 500 mating times | △IL ≤0.2, △RL≤5 | |||
| Fiber Type | G652D (G657A and G657B fiber are optional) | OM3, OM4 | ||
| Cable | Type | Round cable (flat ribbon cable is optional) | ||
| Material | PVC (LSZH is optional) | |||
| Diameter (mm) | 3.0 | |||
| Temperature(°C) | Operating | -20~+75 | ||
| Storage | -20~+75 | |||
SUN-MTP Panel & Cassette
Model: SUN-MTP
19 " Standard rack structure, rack height 1U/4U, big capacity
Features
Easy to install and operate 19-inch standard structure High density, large capacity
SUN-QSFP-LR4 40G Optical Transceiver
Model: SUN-QSFP-LR4
40G QSFP Optical Transceiver,suitable for single mode, max transmitter distance:10km
Features
Transmission data rate up to 11.2Gbps per channel QSFP+ MSA compliant Compliant to IEEE 802.3ba specification for 40GBASE-LR4 links 4 CWDM un-cooled DFB lasers, using ITU G.694.2 wavelength grid at 1271, 1291, 1311, and 1331nm High Sensitivity PIN-TIA with optical DEMUX Up to 10km reach over standard single mode fiber Compliant with QDR/DDR Infiniband data rates Hot pluggable electrical interface Lower power consumption Operating case temperature：Standard: 0~+70°C Operating case temperature：Industrial: -40~+85°C
SUN-AD Fiber Optic Adaptors
Model: SUN-AD
The adapters including FC, SC, ST, LC, MTRJ, MPO (PC ⁄ APC, SM ⁄ MM)
Features
Different interface optional Easy operation Low insertion loss Reuse for single / multimode fiber
SUN-1000 Ethernet Media Converter
Model: SUN-1000
10 ⁄ 100 ⁄ 1000Mbps, 1xRJ45, 1xOptical port
Features
Compliance with IEEE standards MTBF of more than 50000 hours Full & half duplex operation and auto-negotiation Electric interface self-adapting parallel/crossover connections Longest 1552 byte data packet transmission QoS ensuring VoIP data packet transmission STP Spanning Tree forming a redundant network Low power consumption and low heat for longtime stable operation Single/Multi mode and Single/Dual fiber transmission modes Network Management Function (optional)
SUN-OT5000 OTDR
Model: SUN-OT5000
Can test SM and MM fibers, optional light source, VFL and power meter
Features
Quick startup FTTX in-service testing (Up to1:64 splitter) Built-in PON power meter for Triple-play testing High configuration series include optical light source, optical power meter, visual fault locator (VFL) and Optical Connector Inspector (MCI) modules USB data interface (PC software for batch data processing and report output) Dustproof and shockproof (2-meter drop test) Light weight, small size, rugged design and simple operation Visual link image software (Optional)
SUN-PM100L Fiber Optic Polishing Machine
Model: SUN-PM100L
Suitable for mass production
Features
High Speed Process Huge Capacity FC, SC, ST, LC, MU MTP, MPO, MTRJ UPC or APC P.C. Polishing Fixtures 20 connectors: FC, SC, ST 24 connectors: LC & MU Self Adjusting Pressure Exceeds requirements for GR-326 End Face Geometry Uses the new I.P.C. holder technology yields the best results in the industry No variability in result when polishing 1 or 20 connectors Polishes up to 24 connectors: MU & LC & 20 for SC, FC & ST Efficient and fast processes for all connector types Built w/ high quality, heat-treated, stainless steel for amazing precision and durability
